COM Express® mini Type 10 with Intel® Atom™ D2000/N2000 Series
» Intel® Atom™ D2000 & N2000 Series
» Valuable Dual Core technology
» Full-HD and Blu-ray support
» Onboard DDR3 system memory
Compliance COM Express® mini, Pin-out Type 10
Dimensions (H x W x D) 84 x 55 mm
CPU Intel® Atom™ D2550, Intel® Atom™ N2800, Intel® Atom™ N2600
Chipset Intel® NM10 Express Chipset
Main Memory Up to 2GB DDR3-1066 memory down
Graphics Controller Intel® GMA 3650 (D2550, N2800), Intel® GMA 3600 (N2600)
Ethernet Controller Intel® 82574L
Ethernet 10/100/1000 Mbit LAN
Hard Disk 2x SATA 3Gb/s
Flash Onboard 2 - 64GB SATA NANDrive
PCI Express® / PCI support 3x PCIe x1
Panel signal DDI: DP++, LVDS: Single Channel 18/24bit
USB 8x USB 2.0
Serial 2x serial interface (RX/TX only) optional
Audio Intel® High Defi nition Audio
Common Features SPI, LPC, SMB, Fast I²C, Staged Watchdog, RTC, MARS
BIOS AMI Aptio (UEFI)
Humidity 93% relative Humidity at 40°C, non-condensing (according to IEC 60068-2-78)
Options 1x PCIe x1 additional w/o onboard LAN, Trusted Platfom Module TPM 1.2, 2x UART
SATA Flash (2-32GB SLC, 4-64GB MLC), Secure Boot
Power Management ACPI 3.0, S5 Eco
Power Supply 4.75V – 20V Wide Range, Single Supply Power
Special Features POSCAP capacitors
Operating System Windows® 7, WEC7, WES 7, Windows® XP, Linux, VxWorks
Temperature Commercial temperature: 0°C to +60°C operating, -30°C to +85°C non-operating
Extended temperature: -25°C to +75°C operating, -30°C to +85°C non-operating
Industrial temperature: -40°C to +85°C operating, -40°C to +85°C non-operating
